Key Features

Technology: Uses Advanced IGBT inverter technology for high efficiency and energy-saving performance.

Arc Quality: Delivers stable output power and a continuous arc with only slight splash.

Durability: Features low loss of components leading to a long service life.

Advanced Control: Includes manually adjustable functions like HOT-STAR, LIFE TIG, VRD, ARC-FORCE, and ANTI-STICK.

Applications: Capable of use in all decorating and repairing industries, as well as precision welding fields like thin plate welding.

📊 Technical Data (MMA)

Item: SFM400MMA PRO

Input Voltage (V): 1PHASE AC220V~

Input Current (A): 112 A

Input Power Capacity (KVA): 24.6 KVA

Output Current Range (A): 20-400 A

No-load Voltage (V): 72 V

Rated Duty Cycle (%): 60%

Efficiency (%): 85%

Power Factor (cos@): 0.93

Electrode (mm): 1.6-4.0mm

Protection Class: F

Dimension (mm): 372X170X275mm

Weight (kg): 8.9kg

Box Size: 430X225X315

Weight (kg): 8.9+0.5
